Watts 0009188 - LFU5B-LP-Z3 1-1/4" NPT Lead Free High Performance Pressure Reducing Valve, Low Pressure Range 10-35 PSI

Watts 0009188 - LFU5B-LP-Z3 1-1/4" NPT Lead Free High Performance Pressure Reducing Valve, Low Pressure Range 10-35 PSI

$4,335.00 CAD
$4,335.00 CAD
Sale Sold out
Shipping calculated at checkout.

Ships in 2-3 days (Free Shipping)

Watts 0009188 - LFU5B-LP-Z3 1-1/4" NPT Lead Free High Performance Pressure Reducing Valve, Low Pressure Range 10-35 PSI.

This Watts 0009188 LFU5B-LP-Z3 1-1/4" lead free high performance water pressure reducing valve with a lead free cast copper silicon alloy body is equipped for low pressure ranges. It is designed to reduce incoming water pressure to protect plumbing systems and reduce water consumption for commercial, industrial and residential applications. This easy maintenance assembly consists of a replaceable seat module and a bypass feature to control thermal expansion pressure.

Product Features:

  • The connection is 1-1/4" NPT female union x NPT female
  • The temperature range is 33 to 160 degrees F (0.5 to 71 degrees C)
  • The low pressure range is 10 to 35 psi (69 to 241 kPa)
  • With the standard setting at 30 psi (207 kPa).
  • Low pressure applications
  • Serviceable in line without special tools
  • Integral stainless steel strainer removable for cleaning
  • NPT threaded female union inlet by NPT female outlet
  • SKU: 0009188
  • Model: LFU5B-LP-Z3-1-1/4
