Taco 0026E-SF2 - 0026e Series Stainless Steel Variable Speed ECM High-Efficiency Wet Rotator Circulator Pump

Ships in 2-3 days (Free Shipping)

Taco 0026E-SF2 - 0026e Series Stainless Steel Variable Speed ECM High-Efficiency Wet Rotator Circulator Pump.

The 0026E-SF2 circulator is a high-performance, variable speed, wet-rotor circulator with high-efficiency ECM permanent magnet technology. With 5 easy settings, its variable speed performance curves are equivalent to the Taco 0010, 0011, 0012, 0012 3-Speed & 0014. Ideal for large residential and light commercial hydronic heating, chilled water cooling and domestic hot water systems. The 0026e reduces power consumption by up to 85% compared to equivalent AC permanent split capacitor circulators. With a maximum of 26 feet of head and 44 gpm, it is available in either Cast Iron or NSF certified Stainless Steel.

Technical Specs:

• Max. Shut-off Head: 26 ft
• Max. Flow: 44 gpm
• Max. Pressure: 150 psi (10.3 bar)
• Max. Temp: 230° F (110° C)
• Min. Temp: 14°F (-10°C)
• Voltage: 115/208/230V, 50/60Hz Single phase
• Operating Power Range: 10 -125W
• Max. AMP: 1.05A
• Flange-to-flange: 6 ½”

Product Features:

• Easy to install and program.
• Replaces all single speed and 3-speed circulators in its class.
• Rotatable control cover to simplify installation.
• With BIO Barrier that protects the pump from system contaminants.
• Sure Start - automatic unblocking and air purging mode.
• Use with a Taco ZVC Zone Valve Control or SR Switching Relay for ON/OFF operation.
• Nut-grabber feature on flanges for easier fit-up.
• Dual electrical knockouts and removable quick-connect terminal strip for easy wiring.
• Double insulated.
• Whisper quiet operation.
• SKU: Taco 0026E-SF2

Product Specs:

• Specification Sheet
• Installation Instructions
• Manufacturer Page
